Product Description
This product is a desktop hidden network transmission device. It adopts advanced audio and video transmission technology to transmit audio and video signals through a single network cable for 70 meters. The product supports HDMI/VGA/AUDIO signal input and HDBaseT signal output for users. An advanced and beautiful desktop signal connection solution. Plug and play. Support picture quality and color depth adjustment, support 20-level reproduction rate scaling adjustment, a variety of interface options, can be developed for special needs customers.
Features
Support HDMI/VGA/Audio signal input , HDbaseT signal output,Support POC
Industrial grade design,support stable operation for 7*24 hours
Support multiple color spaces RBG444, YUV444, YUV422,x.v.Color extended color gamut
Support 1080P@60Hz: 1080i@60Hz, 720p@60hz, etc.
HDTV format resolution HD signal can also support 1920*1200, etc.
HD signal with VESA format resolution, maximum bandwidth 10.2Gbps
Support signal transmission 70 meters long distance
Parameters
Model | R-TABLE-HDBT |
Name | Table-mountable network extender |
Resolution | Support 640*480/60HZ---1920*1200/60HZ (VESA standard), 480I---1080P (HDTV standard) |
Transmission distance | 70m |
Bandwidth | 10.2GBPS |
Input voltage | DC 12V |
Electrostatic protection | Human body discharge mode: ± 8kV (air gap discharge) ± 4kV (contact discharge)
|
Size(mm) | 160X155X92(w/h/d) Hole size: φ150 |
| Weight | 2.8KG |
| Operating temperature | -10℃---50℃ |
| Storage temperature | -25℃---55℃ |
| Power consumption | 10W |
