2022-11-03 16:32:54   602

UHDW-HDMI88 It is a multi-functional ultra-high-definition matrix control all-in-one machine,with the function of 4*4/8*8 matrix switcher, and supports 4 screen/8 screen splicing display. It is a high-performance, high-bandwidth intelligent switching distribution device specially designed for ultra-high-definition video display systems. Each HDMI channel of the matrix supports the acquisition and display of various resolution formats of 4K@60Hz and below, as well as common 3D formats. Built-in intelligent EDID control, can intelligently read and write the display device information, 8 input channels support independent EDID and can customize the resolution format of each output channel, which can be applied to any high-definition digital video system to meet the user's ultra-clear experience Demand.

  • Brand : KENSENCE
  • Model :
  • Price : Discuss personally

Product overview

UHDW-HDMI88 It is a multi-functional ultra-high-definition matrix control all-in-one machine,with the function of 4*4/8*8 matrix switcher, and supports 4 screen/8 screen splicing display. It is a high-performance, high-bandwidth intelligent switching distribution device specially designed for ultra-high-definition video display systems. Each HDMI channel of the matrix supports the acquisition and display of various resolution formats of 4K@60Hz and below, as well as common 3D formats. Built-in intelligent EDID control, can intelligently read and write the display device information, 8 input channels support independent EDID and can customize the resolution format of each output channel, which can be applied to any high-definition digital video system to meet the user's ultra-clear experience Demand.


Features

  • Supports 8 HDMI input and output;

  • Support 8 channels of 3.5mm audio signal input and output;

  • Support panel buttons, IR infrared, RS232 commands and TCP/IP

    network port control;

  • Support resolution up to 4K x 2K@60Hz, support 1080P 3D;

  • Support output resolution change, which can be selected through

    the EDID button;

  • Integrate a variety of control protocols, which can be used with

  • various central control equipment conveniently and quickly;

  • Can provide on-site remote support and customization of user special functions;

  • Powerful storage function, can store and recall multiple pre-stored switching modes;

  • with power-off memory function, with interrupt Electric field protection function;

  • Fast ultra-clear all-digital switching;

  • Support USB firmware online upgrade;

  • Support LCD or LED screen to display system status in real time;

  • Support HDMI 2.0, compatible with HDCP2.2 protocol and

    backward compatible;

  • Transmission 4Kx2K@60Hz 4:4:4, signal transmission ≥5 meters;

  • Support input HDCP follow, output support HDCP management,

  • command control;


Technical parameters
