2025-06-03 16:24:48   12

More and more users want to integrate operation management, production scheduling, security monitoring, emergency command and other systems.

  • Brand : KENSENCE
  • Model : XMS-9000-ES XMS-9000-DS
  • Price : Discuss personally

More and more users want to integrate operation management, production scheduling, security monitoring, emergency command and other systems. Realize remote presentation of large screen signals, communication between various screens and screens, and form a cloud management platform for information sharing.

Features

1. With video blur mos-aic, with privacy protection; 2. The system integrates splicing wall, preview group, mode save/recall, layout, audio adjustment and other control, subtitle, title, system settings and other functions; 3. to achieve all signal sources in any display terminal seamless switching, windowing, scaling, cross-screen, roaming, superimposed display and can customize the splicing mode. 4. To achieve 9 preview groups, each preview group of 7 windows can be used for real-time preview display of high-definition video; 5. Support a variety of splicing wall layout, can be customized according to demand, support for picture-in-picture, picture outside a variety of combinations; 6. Support for saving a variety of modes, to achieve a key call; 7. can be signal splicing and signal source window push on the big screen, accurate positioning, red box to remind; 8. Embedded management software must be installed in the host, must be based on B / S and native HDMI / VGA video output management interface architecture, B / S compatible with IE and other browsers: 9. Mouse cross-screen, OSD fast switching, take over / push function; 10 external control: XMS-9000 has RS232/485 interface; 11 video transmission: XMS-9000 support optical / network backup and DVI-I signal output.
item
value
Private Mold
NO
Brand Name
Kensence
Model Number
XMS-9000-ES
XMS-9000-DS
Description
XMS-9000-ES 4K Encoder
XMS-9000-DS 4K decoder
Input Video Ports
 1xHDMI
1x LAN 1xFiber
Certifications
CE CCC ISO9001 ISO14001
Input Video Type
 HDMI2.0,HDCP2.2
IP code stream
Input audio port
1xHDMI: Audio ln:1x3.5 mm stereo port
1xLAN:1xFiber
Input Audio Type
HDMI: Compatible with all audio formats supported by HDMI 2.0. Including PCM
2.0/5.1/7.1.DolbyTrueHD.DolbvAtmos.DTS-HD Master Audio and DTS:X;Audio ln: Stereo
LAN/Optical: Compatible with all audio formats supported by HDMI 2.0, including PCM2.0/5.1/7.1, DolbyTrueHD, DolbyAtmos, DTS-HD
Master Audio and DTS:X
Output audio ports
Audio 0ut:1x3.5mm stereo port:1xLAN:1xFiber.1XHDMI
1xHDMI; Audio Out:1x3.5mm stereo port:
USB port
1xUSB3.0.1xUSB2.0
Encoding resolution
 QCIF, CIF, 4CIF(D1), 480P, 576P, 720P, 1080P, 1920x1200,1280x800,1440x900,1366x768,
1280x1024,1024x768,800x600, 3840*2160 [4K
Warranty
1 year
1 year
